Connector/Pin No.	Wire colour	Description	Input/Output
C0092 (brown connector)
1	BG	Rear RH speaker line	Output +
2	BU	Rear RH speaker line	Output -
3	BK	Front RH speaker line	Output +
4	BR	Front RH speaker line	Output -
5	BW	Front LH speaker line	Output +
6	BN	Front LH speaker line	Output -
7	BY	Rear LH speaker line	Output +
8	BO	Rear LH speaker line	Output -
C0098 (grey connector)
1		Telephone mute	Input
2	SB	Steering wheel remote radio controls	Input
3	SR	Steering wheel remote radio controls	Output
4	P	Permanent battery feed	Input
5	RU	System enable	Output
6	RN	Illumination	Input
7	LGP	Auxilary feed	Input
8	B	Earth	Input
C0921 (high line systems)
1	R	Radio headphone left channel	Output +
2	U	Radio headphone right channel	Output +
3		Telephone audio	Input +
4	W	Radio headphone left channel	Output -
5	P	Radio headphone right channel	Output -
6		Telephone audio	Input -
C0922 (high line systems)
7	O	Radio headphone active Input
8		I-BUS communications	Input/Output
9	SG	Audio amplifier spatial imaging enable	Output
10	G	Radio headphone LH remote control	Input
11	S	Radio headphone RH remote contro	Input
12	Y	Headphone remote controls feed	Output
C1354 (high line systems)
13	R	CD-autochanger audio left channel	Input +
14	W	CD-autochanger audio right channel	Input +
15	N	CD-autochanger audio earth	Output
16	S	CD-autochanger audio left channel	Input -
17	B	CD-autochanger audio right channel	Input -
18		Not Used
19	G	CD-autochanger I-BUS communications link	Input/Output
20	P	CD-autochanger permanent feed	Output
